Incandescent Marker Lamps

3.75"x 1.25"

Marker Lamps

Click on images to expand view.

CATALOG PAGE 33

1A-V-1260AR
1A-V-1260AR

2 Bulb, #194 12V 3.75" x 1.25" Standard 2-pole plug PC Lens ABS base FMVSS: P2, PC

L04-0041R
L04-0041R

2 Bulb, #194 12V 3.75" x 1.25" Standard 2-pole plug PC Lens ABS base FMVSS: P2, PC

L04-0041A
L04-0041A

2 Bulb, #194 12V 3.75" x 1.25" Standard 2-pole plug PC Lens ABS base FMVSS: P2, PC

2.5"x 1.25"

Marker Lamps

CATALOG PAGE 33

1A-S-1258R
1A-S-1258R

1 Bulb, #194 12V 2.5" x 1.1/4" Standard 2-pole plug PC Lens ABS base FMVSS: P2, PC, P3, PC2

1A-S-1258A
1A-S-1258A

1 Bulb, #194 12V 2.5" x 1.1/4" Standard 2-pole plug PC Lens ABS base FMVSS: P2, PC, P3, PC2

BASE OPTIONS FOR:

  • 1A-V-1240 Lamps

  • 1A-V-1250 Lamps

  • L04-0041

BASE OPTIONS FOR:

  • 1A-S-1238 Lamps

  • 1A-S-1239 Lamps

  • 1A-S-1258

REFLECTIVE

Marker Lamps

CATALOG PAGE 38, 39, 40, 41

L04-0049R
L04-0049R

6.24" X 1.7/8" Stainless steel bezel Reflective/ PC Lens ABS housing 1 Bulb, #194 12V FMVSS: P2, A Red replacement lens: 1A-S-1900RL LED version: 1A-S-1900R

L04-0049A
L04-0049A

6.24" X 1.7/8" Stainless steel bezel Reflective/ PC Lens ABS housing 1 Bulb, #194 12V FMVSS: P2, A Amber replacement lens: 1A-S-1900AL LED version: 1A-S-1900A

L04-0050A
L04-0050A

6" X 2.1/16" Amber Reflective/ PMMA Lens ABS housing 2 Bulb, #194 12V FMVSS: P2, A

L04-0050R
L04-0050R

6" X 2.1/16" Red Reflective/ PMMA Lens ABS housing 2 Bulb, #194 12V FMVSS: P2, A

L04-0059R
L04-0059R

4" X 2" Red Reflective PC Lens White ABS Base 1 Bulb, #194 12V 2 WIRE BASE FMVSS: P2, P3, A Replacement lens: L04-0059R-lens

L04-0059A
L04-0059A

4" X 2" Amber Reflective PC Lens White ABS Base 1 Bulb, #194 12V 2 WIRE BASE FMVSS: P2, P3, A Replacement lens: L04-0059A-lens

L04-0059R-BLK
L04-0059R-BLK

4" X 2" Red Reflective PC Lens Black ABS Base 1 Bulb, #194 12V 2 WIRE BASE FMVSS: P2, P3, A Replacement lens: L04-0059R-lens

L04-0059A (2)
L04-0059A (2)

4" X 2" Amber Reflective PC Lens Black ABS Base 1 Bulb, #194 12V 2 WIRE BASE FMVSS: P2, P3, A Replacement lens: L04-0059A-lens

1A-S-1300R
1A-S-1300R

4" X 1.5" Red Reflective PMMA Lens White ABS Housing 1 Bulb, #194 12V 1 WIRE BASE FMVSS: P2, P3, A Replacement lens: 1A-S-1320AR

1A-S-1300A
1A-S-1300A

4" X 1.5" Amber Reflective PMMA Lens White ABS Housing 1 Bulb, #194 12V 1 WIRE BASE FMVSS: P2, P3, A Replacement lens: 1A-S-1300AL

1A-S-1320R
1A-S-1320R

4" X 1.5" Red Reflective PMMA Lens White ABS Housing 1 Bulb, #194 12V 2 WIRE BASE FMVSS: P2, P3, A Replacement lens: 1A-S-1320AR

1A-S-1320A
1A-S-1320A

4" X 1.5" Amber Reflective PMMA Lens White ABS Housing 1 Bulb, #194 12V 2 WIRE BASE FMVSS: P2, P3, A Replacement lens: 1A-S-1300AL

L04-0054A
L04-0054A

2.7/8" x 2" Amber Reflective PC Lens Black PC Base Stud Mount 1 Bulb, #194 12V 1 WIRE FMVSS: P2, A

L04-0054R LIT
L04-0054R LIT

2.7/8" x 2" Red Reflective PC Lens Black PC Base Stud Mount 1 Bulb, #194 12V 1 WIRE FMVSS: P2, A

CATALOG PAGE 39

4" X 2"

Marker Lamps

1A-S-90A
1A-S-90A

4" X 2" Amber PC Lens ABS Base 2 Bulb, #194 12V 2 WIRE FMVSS: P2 Replacement lens: 1A-S25A

1A-S-90R
1A-S-90R

4" X 2" Red PC Lens ABS Base 2 Bulb, #194 12V 2 WIRE FMVSS: P2 Replacement lens: 1A-S25R

1A-S-90W
1A-S-90W

4" X 2" Clear PC Lens ABS Base 2 Bulb, #194 12V 2 WIRE FMVSS: P2 Replacement lens: 1A-S25W

WP-B1274 BEZEL
WP-B1274 BEZEL

Chrome plated zinc Brush guard Screw mount

WP-BV11B BEZEL
WP-BV11B BEZEL

Chrome plated plastic Screw mount

CATALOG PAGE 41

2.1/8"x 1.1/8"

Marker Lamps

L04-0055A
L04-0055A

2.1/8" x 1.1/8" Amber PC Lens Metal Base Stud Mount 1 Bulb, #194 12V 1 Bare Wire FMVSS: P2

MARKER LAMPS

w/ BRUSH GUARD

CATALOG PAGE 43







1A-S-20128A
1A-S-20128A

Features: 4.7/8" x 2" 1 Bare Wire 1 Bulb # 194 Amber PMMA lens ABS Housing FMVSS: P2, P3, LED version: L14-0057A

1A-S-20128R
1A-S-20128R

Features: 4.7/8" x 2" 1 Bare Wire 1 Bulb # 194 Red PMMA lens ABS Housing FMVSS: P2, P3, LED version: L14-0057R
