LED Clearance & Marker Lamps

LED MARKER LAMP

10 DIODE

Click on images to expand view.

CATALOG PAGE 24

1A-S-2000R
1A-S-2000R

FEATURES: 6"X2" 10 Diodes 12V 1 Eyelet, 1 terminal Red PC Lens ABS Housing FMVSS: P2

1A-S-2000A
1A-S-2000A

FEATURES: 6"X2" 10 Diodes 12V 1 Eyelet, 1 terminal Amber PC Lens ABS Housing FMVSS: P2

WP-BV12B
WP-BV12B

CHROME PLATED PLASTIC BEZEL

LED SIDEMARKER LAMP

CATALOG PAGE 25

1A-S-1915R
1A-S-1915R

6-1/4" X 1-7/8" 12 Diode 1 eyelet, 1 terminal Stainless steel bezel 3-15/16" screw hole spacing PC Lens ABS housing 12V FMVSS: P2, P3 WP-B20B: Stainless steel bezel option

1A-S-1905A
1A-S-1905A

6-1/4" X 1-7/8" 12 Diode 1 eyelet, 1 terminal Stainless steel bezel 3-15/16" screw hole spacing PC Lens ABS housing 12V FMVSS: P2, P3 WP-B20B: Stainless steel bezel option

1A-S-1905RI
1A-S-1905RI

6-1/4" X 1-7/8" Clear lens 12 Red Diode 1 eyelet, 1 terminal Stainless steel bezel 3-15/16" screw hole spacing PC Lens ABS housing 12V FMVSS: P2, P3 WP-B20B: Stainless steel bezel option

1A-S-1905AI
1A-S-1905AI

6-1/4" X 1-7/8" Clear Lens 12 AMBER Diode 1 eyelet, 1 terminal Stainless steel bezel 3-15/16" screw hole spacing PC Lens ABS housing 12V FMVSS: P2, P3 WP-B20B: Stainless steel bezel option

1A-S-1915R
1A-S-1915R

6-1/4" X 1-7/8" 12 Diode 1 eyelet, 1 terminal Stainless steel bezel 3-15/16" screw hole spacing PC Lens ABS housing 12V FMVSS: P2, P3 WP-B19B: Chrome Hotdog Bezel includes (2) mounting tabs and (2) #6x1" screws.

1A-S-1915A
1A-S-1915A

6-1/4" X 1-7/8" 12 Diode 1 eyelet, 1 terminal Stainless steel bezel 3-15/16" screw hole spacing PC Lens ABS housing 12V FMVSS: P2, P3 WP-B19B: Chrome Hotdog Bezel includes (2) mounting tabs and (2) #6x1" screws.

1A-S-1915 AI or  RI
1A-S-1915 AI or RI

6-1/4" X 1-7/8" Clear lens 12 Red Diode (1A-S--1915RI) 12 Amber Diode (1A-S-1915AI) 1 eyelet, 1 terminal Stainless steel bezel 3-15/16" screw hole spacing PC Lens ABS housing 12V FMVSS: P2, P3 WP-B19B: Chrome Hotdog Bezel includes (2) mounting tabs and (2) #6x1" screws.

LED MARKER LAMP

CATALOG PAGE 25

MULT-DIRECTIONAL

L14-0094R
L14-0094R

FEATURES: 6"X1.75" 10 Diodes 12V 2 Bare wire Verticle & Horizontal Orientation Interior chrome backing Red PMMA Lens ABS Housing FMVSS: P2, P3

L14-0094A
L14-0094A

FEATURES: 6"X1.75" 10 Diodes 12V 2 Bare wire Verticle & Horizontal Orientation Interior chrome backing Amber PMMA Lens ABS Housing FMVSS: P2, P3

LED MARKER LAMPS

CATALOG PAGE 26

15 DIODE: 1A-S-65A
15 DIODE: 1A-S-65A

FEATURES: Cab Marker Lamp 3-1/4"X 2-3/4" 15 Diodes 12V 1 Bare wire, 1 eyelet PC Lens ABS Housing FMVSS: P2, PC

15 DIODE: 1A-S-65R
15 DIODE: 1A-S-65R

FEATURES: Cab Marker Lamp 3-1/4"X 2-3/4" 15 Diodes 12V 1 Bare wire, 1 eyelet PC Lens ABS Housing FMVSS: P2, PC

12 DIODE: L14-0059R
12 DIODE: L14-0059R

FEATURES: 4.5"X 2-1/4" 12 Diodes 12V 2 Bare wire PC Lens ABS Housing FMVSS: P2, P3

12 DIODE: L14-0059A
12 DIODE: L14-0059A

FEATURES: 4.5"X 2-1/4" 12 Diodes 12V 2 Bare wire PC Lens ABS Housing FMVSS: P2, P3

12 DIODE: L14-0026R
12 DIODE: L14-0026R

FEATURES: 5-7/8"X 2" 12 Diodes 12V 2 Bare wire PC Lens ABS Housing FMVSS: P2, P3

12 DIODE: L14-0026A
12 DIODE: L14-0026A

FEATURES: 5-7/8"X 2" 12 Diodes 12V 2 Bare wire PC Lens ABS Housing FMVSS: P2, P3

9 DIODE: L14-0052-NEW
9 DIODE: L14-0052-NEW

FEATURES: 4"X 2" 9 Diodes 12V 2 Bare wire Chrome Base PC Lens ABS Housing FMVSS: P2, P3

9 DIODE: L14-0054-NEW
9 DIODE: L14-0054-NEW

FEATURES: 4"X 2" 9 Diodes 12V 2 Bare wire Chrome Base PC Lens ABS Housing FMVSS: P2, P3

LED MARKER LAMP

CATALOG PAGE 27

2 DIODE: L14-0079R-NEW
2 DIODE: L14-0079R-NEW

FEATURES: 4"x 2" 2 Bare Wire 2 Diode White Base RedPC Lens ABS Housing fmvss: P2, P3

2 DIODE: L14-0079A-NEW
2 DIODE: L14-0079A-NEW

FEATURES: 4"x 2" 2 Bare Wire 2 Diode White Base Amber PC Lens ABS Housing fmvss: P2, P3

6 DIODE: L14-0061R
6 DIODE: L14-0061R

FEATURES: 4"x 1.5" 1 Bare Wire, 1 Eyelet 6 Diode W/ Reflective lens White Base Red PMMA Lens ABS Housing fmvss: P2,A

6 DIODE: L14-0061A
6 DIODE: L14-0061A

FEATURES: 4"x 1.5" 1 Bare Wire, 1 Eyelet 6 Diode W/ Reflective lens White Base Amber PMMA Lens ABS Housing fmvss: P2,A

2 DIODE: 1A-S-97RI
2 DIODE: 1A-S-97RI

FEATURES: 4-1/8"x 2" 2 Bare Wire 16 Red Diodes White Base Clear PC Lens ABS Housing fmvss: P2

2 DIODE: 1A-S-97R
2 DIODE: 1A-S-97R

FEATURES: 4-1/8"x 2" 2 Bare Wire 16 Diodes White Base RED PC Lens ABS Housing fmvss: P2

2 DIODE: 1A-S-97A
2 DIODE: 1A-S-97A

FEATURES: 4-1/8"x 2" 2 Bare Wire 16 Diodes White Base AMBER PC Lens ABS Housing fmvss: P2

2 DIODE: 1A-S-97AI
2 DIODE: 1A-S-97AI

FEATURES: 4-1/8"x 2" 2 Bare Wire 16 Amber Diodes White Base Clear PC Lens ABS Housing fmvss: P2

LED MARKER LAMP

CATALOG PAGE 28

7 DIODE: 1A-S-2300RI
7 DIODE: 1A-S-2300RI

Features: 4"x 3/4" 1 Eyelet, 1 terminal 7 Red Diodes Clear PC lens ABS Housing 12V fmvss: P2, P3

7 DIODE: 1A-S-2300R
7 DIODE: 1A-S-2300R

Features: 4"x 3/4" 1 Eyelet, 1 terminal 7 Diodes RED PC lens ABS Housing 12V fmvss: P2, P3

1A-S-2300AI
1A-S-2300AI

Features: 4"x 3/4" 1 Eyelet, 1 terminal 7 AMBER Diodes Clear PC lens ABS Housing 12V fmvss: P2, P3

7 DIODE: 1A-S-2300A
7 DIODE: 1A-S-2300A

Features: 4"x 3/4" 1 Eyelet, 1 terminal 7 Diodes AMBER PC lens ABS Housing 12V fmvss: P2, P3

LED MARKER LAMP

w/ BRUSH GUARD

CATALOG PAGE 43

L14-0057R
L14-0057R

Features: 4.7/8" x 2" 1 Bare Wire 6 Diodes Red PMMA lens ABS Housing FMVSS: P2, P3, PC, PC2 Incandescent version: 1A-S-20128R

L14-0057A
L14-0057A

Features: 4.7/8" x 2" 1 Bare Wire 6 Diodes Amber PMMA lens ABS Housing FMVSS: P2, P3, PC, PC2 Incandescent version: 1A-S-20128A

LED 3/4" MARKER LAMPS

CATALOG PAGE 28

L14-0110A
L14-0110A

3/4" Round Marker-AMBER 2 Diode Rubber Grommet Mount 10" bare wire leads Sealed Tested at 12V PC Lens FMVSS: PC2, P3, PC

L14-0110R
L14-0110R

3/4" Round Marker-RED 2 Diode Rubber Grommet Mount 10" Bare wire leads Sealed Tested at 12V PC Lens FMVSS: PC2, P3, PC

L14-0110A-SHEATH
L14-0110A-SHEATH

3/4" Round Marker 2 Diode Rubber Grommet Mount Sealed W/ Sheath and 10" wire leads Tested at 12V PC Lens FMVSS: PC2, P3, PC

L14-0110AI or RI
L14-0110AI or RI

3/4" Round Marker 2 Colored Diodes Rubber Grommet Mount 10" Bare wire leads Sealed Tested at 12V CLEAR PC Lens FMVSS: PC2, P3, PC L14-0110AI: Amber Diodes L14-0110RI: Red Diodes

L14-0112R
L14-0112R

3/4" Round Marker-RED 2 Diode Rubber Grommet Mount 10" Bare wire leads w/ Bullet Ends Sealed Tested at 12V PC Lens FMVSS: PC2, P3, PC L14-0112A : AMBER LENS

All other 3/4 inch options
All other 3/4 inch options

LED "CANNOLI" MARKER LAMPS

CATALOG PAGE 29

L14-0098A
L14-0098A

"Cannoli" Marker Features: 5.5"x 1.58" 2 Diode Surface Mount 2 Bare Wire 12V Amber PC Lens Chrome plated ABS Bezel

L14-0098R
L14-0098R

"Cannoli" Marker Features: 5.5"x 1.58" 2 Diode Surface Mount 2 Bare Wire 12V RED PC Lens Chrome plated ABS Bezel

L14-0097R
L14-0097R

"Cannoli" Marker Features: 4.5"x 1.53" 2 Diode Surface Mount 2 Bare Wire 12V RED PC Lens Chrome plated ABS Bezel

L14-0097A
L14-0097A

"Cannoli" Marker Features: 4.5"x 1.53" 2 Diode Surface Mount 2 Bare Wire 12V Amber PC Lens Chrome plated ABS Bezel

L14-0096A
L14-0096A

"Cannoli" Marker Features: 3.5"x 1.43" 2 Diode Surface Mount 2 Bare Wire 12V Amber PC Lens Chrome plated ABS Bezel

LED OVAL MARKER LAMPS

CATALOG PAGE 29

L14-0088A
L14-0088A

Oval Marker Features: Amber w/ Reflex 2 Diode 0.041amps 2" Screw hole spacing Surface Mount 2 Bare Wire 12V PMMA Lens Chrome plated ABS Bezel FMVSS: P2, A

L14-0088R
L14-0088R

Oval Marker Features: Red w/ Reflex 2 Diode 0.041amps 2" Screw hole spacing Surface Mount 2 Bare Wire 12V PMMA Lens Chrome plated ABS Bezel FMVSS: P2, A

L14-0088R-BLK
L14-0088R-BLK

Oval Marker Features: Red w/ Reflex 2 Diode 0.041amps 2" Screw hole spacing Surface Mount 2 Bare Wire 12V PMMA Lens BLACK ABS Housing FMVSS: P2, A

L14-0088R-BLK
L14-0088R-BLK

Oval Marker Features: Amber w/ Reflex 2 Diode 0.041amps 2" Screw hole spacing Surface Mount 2 Bare Wire 12V PMMA Lens BLACK ABS Housing FMVSS: P2, A

LED 1238-40 SERIES MARKER LAMPS

CATALOG PAGE 30

1A-S-1238RI & AI
1A-S-1238RI & AI

Clear Lens AI: 3 Amber Diodes RI: 3 Red Diodes FEATURES: 2.5" x 1" Standard 2 pole plug PC Lens ABS Housing FMVSS: P2, P3

1A-S-1238R
1A-S-1238R

FEATURES: 2.5" x 1" 3 Diodes Standard 2 pole plug Red PC Lens ABS Housing FMVSS: P2, P3

1A-S-1238A
1A-S-1238A

FEATURES: 2.5" x 1" 3 Diodes Standard 2 pole plug Amber PC Lens ABS Housing FMVSS: P2, P3

1A-S-1239R
1A-S-1239R

FEATURES: 2.5" x 1" 3 Diodes Standard 2 pole plug Red PC Lens ABS Housing FMVSS: P2, P3, PC, PC2

1A-S-1239A
1A-S-1239A

FEATURES: 2.5" x 1" 3 Diodes Standard 2 pole plug Amber PC Lens ABS Housing FMVSS: P2, P3, PC, PC2

1A-V-1240AR
1A-V-1240AR

FEATURES: 3.75" x 1.25" 12 Diodes Standard 2 pole plug Amber/ Red PC Lens ABS Housing FMVSS: Auxiliary Only

1A-V-1240R
1A-V-1240R

FEATURES: 3.75" x 1.25" 12 Diodes Standard 2 pole plug Red PC Lens ABS Housing FMVSS: P2, PC

1A-V-1240A
1A-V-1240A

FEATURES: 3.75" x 1.25" 12 Diodes Standard 2 pole plug Amber PC Lens ABS Housing FMVSS: P2, PC

1A-V-1240AI & RI
1A-V-1240AI & RI

Clear Lens AI: Amber Diodes RI: Red Diodes FEATURES: 3.75" x 1.25" 12 Diodes Standard 2 pole plug Clear PC Lens ABS Housing FMVSS: P2, PC

1A-V-1250R
1A-V-1250R

FEATURES: 4" x 1" 6 Diodes Standard 2 pole plug Red PC Lens ABS Housing FMVSS: PC, P2

1A-V-1250A
1A-V-1250A

FEATURES: 4" x 1" 6 Diodes Standard 2 pole plug Amber PC Lens ABS Housing FMVSS: PC, P2

BASE OPTIONS FOR:

  • 1A-V-1240 Lamps

  • 1A-V-1250 Lamps

  • L04-0041

CATALOG PAGE 34

1A-V-12612
1A-V-12612

Fits 4" x 1" marker Black Base 1 Bare Wire 3" screw hole spacing

1A-V-12612G
1A-V-12612G

Fits 4" x 1" marker Gray Base 1 Bare Wire 3" screw hole spacing

1A-V-12612CT
1A-V-12612CT

Fits 4" x 1" marker Chrome Base 1 Wire w/ bullet 1 Terminal end 3" screw hole spacing

1A-V-12612FT
1A-V-12612FT

For 4" x 1" Marker Black Base/Bracket For frame mount 1 Bare Wire 14" Long

CATALOG PAGE 33

BASE OPTIONS FOR:

  • 1A-S-1238 Lamps

  • 1A-S-1239 Lamps

  • 1A-S-1258

1A-V-12612
1A-V-12612

Fits 4" x 1" marker Black Base 1 Bare Wire 3" screw hole spacing

1A-V-12612G
1A-V-12612G

Fits 4" x 1" marker Gray Base 1 Bare Wire 3" screw hole spacing

1A-V-12612CT
1A-V-12612CT

Fits 4" x 1" marker Chrome Base 1 Wire w/ bullet 1 Terminal end 3" screw hole spacing

1A-V-12612FT
1A-V-12612FT

For 4" x 1" Marker Black Base/Bracket For frame mount 1 Bare Wire 14" Long

LED 3.7/8 X 2" MARKER LAMPS

CATALOG PAGE 34

1A-S-68R
1A-S-68R

Red Lens FEATURES: 3.7/8" x 2" 14 Diodes 2 Bare wire PC Lens ABS Housing FMVSS: P2, P3, PC, PC2

1A-S-68A
1A-S-68A

Amber Lens FEATURES: 3.7/8" x 2" 14 Diodes 2 Bare wire PC Lens ABS Housing FMVSS: P2, P3, PC, PC2

1A-S-68AI or RI
1A-S-68AI or RI

Clear Lens AI: Amber Diodes RI: Red Diodes FEATURES: 3.7/8" x 2" 14 Diodes 2 Bare wire PC Lens ABS Housing FMVSS: P2, P3, PC, PC2

FOR KII SIGNATURE SERIES MARKERS

CLICK ON SERIES IMAGE

CHARGER JR MARKERS
CHARGER JR MARKERS
BOW-TIE MARKERS
BOW-TIE MARKERS

Reflective Marker Lamp

CATALOG PAGE 36

L14-0071A
L14-0071A

2.7/8" X 2" 2 Diodes Stud Mount 1 Bare Wire Reflective Lens PC Amber Lens & Black Base FMVSS: P2, A (see Incandescent version L04-0054A, on page 41)

LED MARKER BASE COMBO

CATALOG PAGE 36

L04-0061R
L04-0061R

Red Lens FEATURES: 5" x 1.25" 6 Diodes 2 Bare wire Surface Mount 12V Black Base FMVSS: P2, PC2, PC, P3

L04-0061RI
L04-0061RI

Clear Lens FEATURES: 5" x 1.25" 6 Red Diodes 2 Bare wire Surface Mount 12V Black Base FMVSS: P2, PC2, PC, P3

L04-0061A
L04-0061A

Amber Lens FEATURES: 5" x 1.25" 6 Diodes 2 Bare wire Surface Mount 12V Black Base FMVSS: P2, PC2, PC, P3

L04-0061AI
L04-0061AI

Clear Lens FEATURES: 5" x 1.25" 6 Amber Diodes 2 Bare wire Surface Mount 12V Black Base FMVSS: P2, PC2, PC, P3
